- 1000VA line-interactive Smart-UPS C with SmartConnect cloud monitoring in a 2U rackmount chassis
- 120V, NEMA 5-15R outlets — designed for small business servers, network closets, and workstation racks
- SmartConnect port enables free cloud-based status monitoring and email alerts without a dedicated network card
- USB and SmartSlot accessory bay for optional Network Management Card
- TAA compliant for U.S. federal procurement
- 3-year UPS warranty; user-replaceable battery cartridge available from Questyme
Product Highlights
Documents
Description
APC Smart-UPS C SMC1000-2UC — 1000VA Smart-UPS with SmartConnect Cloud Monitoring
The SMC1000-2UC is part of APC's Smart-UPS C series — an accessible entry to the Smart-UPS line for small business environments that need Smart-UPS power quality without the full feature set of the higher-tier SMT series. It delivers 1000VA of line-interactive pure sine wave power with SmartConnect cloud monitoring built in.
SmartConnect Cloud Monitoring
The Smart-UPS C series introduces APC SmartConnect — a free cloud-based monitoring service accessible through any browser. Receive proactive email alerts on power events, view UPS status remotely, and get firmware update notifications without deploying a Network Management Card or VPN access.
Key Features
- Pure Sine Wave Output: Compatible with active PFC server power supplies and sensitive electronics.
- Automatic Voltage Regulation: Corrects brownouts and surges without battery cycling.
- SmartConnect Cloud Port: Free cloud monitoring, email alerts, and firmware notifications.
- SmartSlot Accessory Bay: Add a Network Management Card for SNMP management when needed.
- LCD Display: Real-time status, load, runtime, and event history at the unit.
- 2U Rackmount Form Factor: Standard 19-inch rack mounting with sliding rails.
Technical Specifications
| Specification | Value |
|---|---|
| VA | 1000VA |
| Topology | Line Interactive |
| Output Waveform | Pure Sine Wave |
| Voltage | 120V |
| Output Outlets | 8x NEMA 5-15R |
| Form Factor | 2U Rackmount |
| Management | SmartConnect + SmartSlot |
| TAA Compliance | Yes |
| Warranty | 3-year UPS / 2-year battery |
Ideal Applications
- Small Business Servers and NAS: Backup for primary file/email/application servers in small offices.
- Network Closets: Switch and router backup at branch offices and small commercial sites.
- Workstation Backup: CAD, financial, and creative workstations where unsaved work is at risk.
- Retail and Hospitality: POS controllers and back-office systems.
- Distributed Multi-Site Deployments: SmartConnect cloud monitoring simplifies fleet visibility across many sites.
Multi-Site UPS Deployments — Questyme Helps Coordinate
Rolling out Smart-UPS C units across multiple branches, clinics, or remote offices benefits from coordinated configuration, consistent SmartConnect enrollment, and consolidated shipping. Questyme stages multi-site deployments to reduce per-site installation time. Contact our team for deployment planning.
Specifications
Overview
Model
APC Smart-UPS C 1000VA LCD RM 2U 120V with SmartConnect
Main
Input Voltage
120
Output Voltage
120
Rated Power in W
600 W
Rated Power in VA
1000
Input Connection Type
NEMA 5-15P
Output Connection Type
6 NEMA 5-15R
Max Configurable Power in VA
1000 VA
Max Configurable Power in W
600 W
Topology
Line Interactive
Battery Type
Lead-Acid battery
Removable Battery
User replaceable
Wave Type
Sine wave
Number of Cables
1
Physical
Color
Black
Mounting Mode
Rack-mounted
Mounting Preference
Lower
Product Line
SMART-UPS UNDER 1.5 KV
Shipping Dimensions
Height: 9.25Width: 22.44Length: 21.06
Shipping Weight
45.66 lb
UPC Code
731304322733
Lead time
Usually Ships within 2 Weeks
Provided Equipment
Documentation CD
Installation guide
Rack Mounting brackets
USB cable
Installation guide
Rack Mounting brackets
USB cable
Product Certifications
cULus
ENERGY STAR V2.0 (USA)
ENERGY STAR V2.0 (USA)
Environmental
Carbon Footprint (kg CO₂ eq, Total Life Cycle)
923
Packaging Made with Recycled Cardboard
Yes
Packaging without Single Use Plastics
No
Ambient Air Temperature for Operation
32-104 ?F (0-40 ?C)
Ambient Air Temperature for Storage
5-113 ?F (-15-45 ?C)
Acoustic Level
41 dBA
Relative Humidity
0-95 %
Storage Relative Humidity
0-95 %
Operating Altitude
0-10000 ft
Storage Altitude
0-50000 ft (0.0000000000-15240.0000000000 m)
Packaging / Certifications
Unit Type of Package 1
PCE
Packaging Made with Recycled Cardboard
Yes
Packaging without Single Use Plastics
No
Take-back
Yes
EU RoHS Directive
Compliant with Exemptions
